İKİ ÇIKIŞLI RD SERİLERİ
- Universal AC giriş / Tam skala
(D-120, RD-125 anahtar ile AC giriş seçimli) - Korumalar: Kısa devre, aşırı yük, aşırı voltaj
- Serbest hava akışı soğutmalı
- Küçük boyutlu, yüksek güç yoğunluklu
- %100 tam yük testi
- 2 yıl garanti
İKİ ÇIKIŞLI RD SERİLERİ
Ürün Kodu | Güç | Çıkış Vdc | Çıkış-1 | Çıkış-2 | Çıkış-3 | Çıkış-4 | Boyut |
RD-35A | 35W | 5/12V | 5V/0.3-4A | 12V/0.2-1A | --- | --- | 99x82x36mm |
RD-35B | 35W | 5/24V | 5V/0.3-2.2A | 24V/0.2-1A | --- | --- | 99x82x36mm |
RD-50A | 50W | 5/12V | 5V/0.3-6A | 12V/0.3-2A | --- | --- | 99x82x36mm |
RD-50B | 50W | 5/24V | 5V/0.3-4A | 24V/0.2-1.4A | --- | --- | 99x82x36mm |
RD-65A | 65W | 5/12V | 5V/0.3-6A | 12V/0.2-3A | --- | --- | 129x98x38mm |
RD-65B | 65W | 5/24V | 5V/0.3-4A | 24V/0.2-2A | --- | --- | 129x98x38mm |
RD-85A | 85W | 5/12V | 5V/2-8A | 12V/0.3-4A | --- | --- | 129x98x38mm |
RD-85B | 85W | 5/24V | 5V/2-8A | 24V/0.3-2A | --- | --- | 129x98x38mm |
RD-125A | 125W | 5/12V | 5V/2-7.7A | 12V/0.5-7.7A | --- | --- | 129x98x38mm |
RD-125B | 125W | 5/24V | 5V/2-4.6A | 24V/0.4-4.6A | --- | --- | 129x98x38mm |
RD-125-2412 | 133W | 24/12V | 24V/0.5-3.7A | 12V/1-3.7A | --- | --- | 129x98x38mm |
RD-125-2448 | 144W | 24/48V | 24V/0.5-2A | 48V/0.2-2A | --- | --- | 129x98x38mm |
RD-125-4812 | 138W | 48/12V | 48V/0.3-2.3A | 12V/1-2.3A | --- | --- | 129x98x38mm |
RD-125-4824 | 144W | 48/24V | 48V/0.3-2A | 24V/0.3-2A | --- | --- | 129x98x38mm |
RD-125-1224 | 133W | 12/24V | 12V/1-3.7A | 24V/0.4-3.7A | --- | --- | 129x98x38mm |
RD-125-1248 | 138W | 12/48V | 12V/1-2.3A | 48V/0.2-2.5A | --- | --- | 129x98x38mm |
